Application
TV & LAN Cables.
Type
Computer Cable
Size
Cat 5e & Cat 6 (with seperator)
Multi Strand Single Core Unsheathed Flexible Cables With Bright Annealed Electrolytic Copper Conductor For Voltage Grade Upto 1100 Volts.
| Conductor Area(Sq.mm) | Current Carrying Capacity(AMPS) | Nos & Dia. Of wire | PVC Thickness | Approx. overall Dia. | Master Box Packing |
|---|---|---|---|---|---|
| 0.50 sq.mm. | 5 | 16/0.20 | 0.60 | 2.30 | 20 |
| 0.75 sq.mm. | 7 | 24/0.20 | 0.60 | 2.50 | 18 |
| 1.00 sq.mm. | 11 | 14/0.30 | 0.60 | 2.70 | 15 |
| 1.50 sq.mm. | 15 | 22/0.30 | 0.70 | 3.20 | 12 |
| 2.50 sq.mm. | 20 | 36/0.30 | 0.80 | 3.70 | 8 |
| 4.00 sq.mm. | 30 | 56/0.30 | 0.80 | 4.30 | 8 |
| 6.00 sq.mm. | 35 | 85/0.30 | 0.80 | 5.20 | 5 |
